Syntho-Shield®

Corrosion protection tape coating Syntho-Shield® system is comprised of three components; a Petrolatum primer/tape system undercoating for long term corrosion protection, Syntho-Glass® XT for mechanical protection, and Syntho-Glass® SPF as a final mechanical and UV protection barrier. The Petrolatum Tape under coating is composed of a non-woven synthetic fabric carrier, fully impregnated with a neutral compound based on saturated petrolatum and inert siliceous fillers. The tapes are designed to provide long term corrosion protection to pipes, flanges, valves, and related surfaces. This unique protective coating system has been designed as an effective solution to corrosion, insulation, and waterproofing problems. Syntho-Glass XT, a fiberglass cloth impregnated with a water activated resin, is used as a protective outer wrap. Syntho Glass SPF is a UV-stable fiberglass cloth impregnated with a unique water-activated resin as a final, outer wrapping for additional mechanical and UV protec-tion. Syntho-Shield is an innovative system that offers exceptional mechanical and impact strength for under water, underground and above ground corrosion protection coating applications.



TYPICAL APPLICATIONS
Corrosion, insulation, sealing, and waterproof protection for:
♦ Pipes, flanges, joints and valves for underwater, above and below ground
Underwater pipelines and platform rig superstructures
♦ Concrete, steel and wooden pilings, in the splash zone, above and below water line
♦ Jetty, bridge and pier pilings, as well as, superstructure supports
♦ Oil, water and chemical pipelines for underwater, above and below ground
♦ Municipalities' water and wastewater treatment piping systems
♦ Industrial and institutional plant piping and duct systems

BENEFITS
♦ Applied to marginally prepared surfaces (SSPC SP 2-3)
♦ Resistant to temperature extremes
♦ Easy to apply, no mixing or messy clean up
♦ Resistant to water, acids, salts or soil organics
♦ Can be applied to wet surfaces and underwater
♦ Minimal surface preparation required
♦ Quick, long term protective coating, ready for immediate service
♦ Contains no solvent
♦ Meets AWWA C217 Standard
